AUDIO SPECIFICATIONS

NUMBER OF CHANNELS: 2

FIXED OUTPUT LEVEL: N/A

VARIABLE OUTPUT LEVEL: N/A

OUTPUT IMPEDANCE: N/A

FREQUENCY RESPONSE: N/A

SIGNAL TO NOISE RATIO: N/A

DYNAMIC RANGE: N/A

TOTAL HARMONIC DISTORTION: N/A

CHANNEL SEPARATION: N/A

HEADPHONE OUTPUT IMPEDANCE: N/A



DIGITAL AUDIO SPECIFICATIONS

DIGITAL OUTPUT SAMPLE RATE: Coaxial: Up to 24-bit/192kHz; Optical: Up to 24-bit/192kHz; MCT: Up to 24-bit/96kHz (CD); DSD128 (SACD and Data DVD)

DIGITAL OPTICAL OUTPUT: -15dbm to -21dbm

DIGITAL COAXIAL OUTPUT: 0.5V p-p/75 ohms

DIGITAL MCT (DIN) OUTPUT: 3V @110 ohms



CONNECTIVITY

DIGITAL COAXIAL OUTPUT: 1

DIGITAL OPTICAL OUTPUT: 1

DIGITAL MCT (DIN) OUTPUT: 1



WEIGHTS & DIMENSIONS

DIMENSIONS (W X H X D): 11-1/2" (29.2cm) x 5-7/8" (14.9cm) x 19" (48.3cm) Note: When the Disc Tray is opened, the panel clearance required in front of mounting panel is 6-3/4 inches (17.2cm)

WEIGHT: 18.5 lbs (8.4 kg)

SHIPPING WEIGHT: 33 lbs (15 kg)
