| Continu uitgangsvermogen: |
30 W + 30 W (8 Ω)
60 W + 60 W (4 Ω) |
| Totale harmonische vervorming: |
0.005% or less (8Ω, 1kHz)
0.02% or less (8Ω, 20Hz to 20kHz) |
| Voorversterker ingangsgevoeligheid/ingangsimpedantie: |
PHONO (MM): 2.5 mV / 47 kΩ
PHONO (MC): 0.3 mV / 100 Ω
LINE: 180 mV / 47 kΩ
MONITOR: 180 mV / 47 kΩ
BAL. LINE: 180 mV / 55 kΩ |
| Eindversterker ingangsgevoeligheid/ingangsimpedantie: |
MAIN-IN: 550 mV / 47 kΩ |
| Uitgangsspanning: |
REC OUT: 180 mV
PRE-OUT: 1 V |
| Signaal / ruisverhouding (IHF-A): |
PHONO (MM):91 dB or more (IHF-A gewogen, 5 mV input, line straight on)
PHONO (MC):75 dB or more (IHF-A gewogen, 0.5 mV input, line straight on)
LINE:105 dB or more (IHF-A weighted, input shorted, line straight on) |
| Frequentiebereik: |
PHONO (MM): 20 Hz to 20,000 Hz (±0.5 dB, line straight on)
PHONO (MC): 20 Hz tot 20,000 Hz (±0.5 dB, line straight on)
LINE: 20 Hz tot 100,000 Hz (within –3 dB, line straight on) |
| Toon control: |
Max. regeling
BASS: ±8 dB at 100 Hz
TREBLE: ±8 dB at 10 kHz |
| Loudness control |
100 Hz: +7 dB
10 kHz: +5 dB |
| Dempingsfactor |
320 |
| Stroomverbruik: |
330 Watt
260 Watt (geen signaal)
0,5 Watt (stand-by) |
| Afmetingen: |
440 (breedte) × 193 (hoogte) x 463 (diepte) mm |
| Gewicht: |
28.4 kg |
