Mark Levinson 585

Dit is toch wel een van de fijne Levinson's van de laatste tijd. Geweldige geintegreerde versterker met power souplesse en detail.



In prima conditie en compleet met verpakking en toebehoren.

Technische Specificaties

Amplifier Section Output Power	200W RMS per channel @ 8 Ω, 20Hz – 20kHz
Amplifier Section Damping Factor	>400 @ 20Hz, referred to 8 Ω
Amplifier Section Frequency Response	20Hz – 20kHz, ±0.13dB; 2Hz – 250kHz, +0.2dB/–3dB
Amplifier Section Signal-to-Noise Ratio	>98dB (20Hz – 20kHz, unweighted); >103dB (20Hz – 20kHz, A-wtd), referred to full output – maximum volume setting
Amplifier Section Voltage Gain	40.7dB (maximum volume setting)
Amplifier Section Total Harmonic Distortion	<0.01% @ 1kHz, 200W, 8 Ω; <0.1% @ 20kHz, 200W, 8 Ω
Preamplifier (Analog) Input Impedance	>45k Ω (RCA & XLR)
Preamplifier (Analog) Input Overload	>5.5V RMS (RCA & XLR)
Preamplifier (Digital) Sample Rates/Bit Depth	PCM 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz/up to 32-bit; DSD Native, single- and double-speed
Analog Audio Connectors	3 pairs single-ended inputs (RCA); 1 pair balanced inputs (XLR); 1 pair single-ended line outputs (RCA); 1 pair loudspeaker outputs ("Hurricane" binding posts w/banana sockets that accept spade lugs with 1/4" (6.3mm) spacing up to 1/8" (3mm) thick)
Digital Audio Connectors	1 balanced AES/EBU input (XLR); 2 coaxial S/PDIF inputs (RCA); 2 optical inputs (Tos-Link); 1 asynchronous USB input (USB-B)
Control Connectors	1 RS-232 port (RJ-12 connector); 1 IR input (1/8" phone jack); 1 programmable 12V DC trigger output (1/8" phone jack), 100mA maximum; 1 programmable 12 DC trigger input (1/8" phone jack); 1 Ethernet port (RJ-45 connector)
Mains Voltage	100V AC, 115V AC, or 230V AC (factory-set)
Power Consumption	Maximum 1000W (power on)
Unit Dimensions (H x W x D)	6.9" (175mm) – without feet; 7.59" (193mm) – with feet x 17.25" (438mm) x 19.95" (507mm)
Packaging Dimensions (H x W x D)	19" (483mm) x 26" (660mm) x 26" (660mm)
Weight	72 lb (32.6kg) – net; 96 lb (43.4kg) – with packaging
